Sammy Build

Post by **Jwlman** » Tue Feb 02, 2010 9:09 am

Build specs:
88? Samurai
vw 1.9L TD
Toy transmission, TC and axles
SOA with Yj springs
Armor all around
Caged
33 inch mud tar on bead locks

We will be using mostly kits to do the upgrades as I am the only one in the family with rig building experience and I won't be able to devote enough time required to custom make a bunch of the stuff. My brother is more into bikes ( you can see a few in his garage) and my Dad is into anything that is interesting, cool, floats, drives or moves. :lol2:

Here is the condition we got it in except we slapped on a new front bumper so that we could flat tow it back to Richmond

In my brothers garage ready for the tear down to begin.

Progress we made during the week between Christmas and new years

More later, gotta run to class

Post by **Jwlman** » Wed Feb 03, 2010 11:52 am

No pics but the current status is that we are down to a bare frame. Frame needs to be cleaned and painted and then we are going to start installing the suspension.

Ordered these brackets for the yj spring conversion.
http://polyperformance.com/shop/Suzuki- ... 19939.html
http://polyperformance.com/shop/Suzuki- ... 19940.html

Body is in pretty good shape but has some rust spots underneath that need to be repaired.

Post by **Arya Ebrahimi** » Wed Feb 03, 2010 12:40 pm

Looking good, can't wait to see how it turns out!

Post by **Jwlman** » Thu Feb 04, 2010 3:32 pm

Anyone have suggestions on a good rebuild kit for a 85 toy front axle and one for the rear too?

Post by **Stinson** » Thu Feb 04, 2010 4:35 pm

Marlin/Allpro/Trailgear

There has been some complaints about the quality of trunion bearings in the TG kit tho. You should try out the TG truinion bearing eliminator kit.

Post by **MtnToys** » Thu Feb 04, 2010 9:36 pm

Definitely get marlins HD front inner axle seals and his rear axle seals. The rest of the stuff is cheaper from trail gear. I haven't had any problems with their bearings.

Post by **Jwlman** » Tue Sep 14, 2010 3:10 pm

Post by **Jwlman** » Tue Sep 14, 2010 3:12 pm

Body should be back on within the next couple days and then we are going to tow it over to the warehouse so I don't have to keep shuffling tools back and froth between it and my jeep

Post by **Jwlman** » Mon Sep 20, 2010 9:42 am

Post by **Jwlman** » Tue Oct 12, 2010 5:58 pm

Mounted up a Toy steering box last weekend. The stock samurai box is located on the inside of the frame rails and further back so we had to cut out a grill mount, and the old steering box mount. Then added a reinforcement plate and cut away some fender and grill to make it all fit
