Terry's Xterra

[TerryD]

Terry's 2007 Xterra S

Driveline:
New Transmission and Radiator
Differential Breather Extension
Secondary Timing Set TSB (5/15/17)
Magnaflow Primary Cats (6/19/18)
Replaced Heater Tees (6/29/19)
2011 P4X M226 3.69 E-Locker/R180 (4/3/20)
QX56 Front CVs (5/6/23)

Suspension:
Removed Rear Swaybar
285/75/16 Nitto Terra Grapplers (5/7/21)
Melt Mod
Front Extended-ish Radflos with 650lb/in Springs (5/23/18)
Rear Radflo 2.0 Emulsion Shocks (4/14/18)
Timbren Rear Bumpstops (4/14/18)
Alcans +2" +450lb (4/14/18)
PRG U-Bolt Flip Kit (4/14/18)
SPC Titan UCAs (5/31/23)
Stock Titan LCAs (5/6/23)
Removed Front Swaybar (9/20/18)
2" PRG Coilover Spacers (5/6/23)
Nisstec Titan Swap Brake Hoses (5/6/23)
PRG TRE Extensions (5/6/23)
Z1 Cam Bolt Lockout Kit (5/6/23)
SuperPro Steering Rack Bushings (10/13/18)
Energy Suspension 9.9101G Front Bump Stops (6/10/23)
PRG Shackles

Interior:
Raingler Upper Barrier Net
Raingler Full Attic Net (6/16/17)
Blue Ridge Overland Gear Medium Med Pack (1/1/18)
Weathertech Floor Mats F&R
Raingler 1/2 Barrier Net (1/9/20)
Kenwood Excelon DPX794BH CD/BT/USB Stereo (4/24/20)
Carling Contoura V Locker/VDC/Compressor Switches (4/24/20)
Ram Phone and Tablet mounts
Custom rear drawer set
Dual Hep's MOLLE window panels
Gentex GNTX-202 Temp/Comp Mirror (7/3/22)

Exterior:
Matching Spare Wheel
Luyed LED Backup bulbs (6/26/17)
Eagle Eye Black Bezel Headlights
@KWSRStorm Cheap Roof Rack (2/16/18)
Frontrunner fold-down table (2/9/22)
2017+ Titan LED fog lights (2/28/22)
Z1 Offroad 2" Wheel Spacers (5/6/23)

Armor/Protection/Recovery
Full set of Shrockworks Skids
White Knuckle 10* Sliders (12/1/17)
ARB CKMA12 Single Compressor (3/23/23)
Shrockworks front bumper (9/20/18)
Warn Zeon 10S winch (9/20/18)
Tuffy Flip Up License Plate Bracket (9/25/18)
ARB M226 rear diff cover
Maxgear tire carrier rear bumper (2/4/22)

Communication:
Lip mount nmo with 2m/440 Tram antenna
Kenwood TM-D710Ga 2m/440 Dual Band Radio with APRS (3-22-19)


[BadAssEddie]

Kid I knew in HS had a cool Xterra. Gotta get some AT's on that. Don't want people to mistake you for a soccer mom

Took me forever to find this picture:

[TerryD]

Wife is going back to school now, soccer mom is my new career goal!

[VerticalTRX]

Looks good

Ditch the running boards, throw some AT's on it and lets head to Uwharrie.

[TerryD]

Thanks to Sam and Wong, I have 2" spacers and newer struts for the front and I picked up some factory off-road package skids and a set of adjustable, extended shackles for it. Looking for some 285s and the time to get it all installed now.

[TerryD]

New treads:

New Tires by TerryD, on Flickr

Anybody up for a wrenching day soon? I got a bunch of lift stuff laying in the floor of the garage that needs installed....

[TerryD]

Doing some lift prep this evening. Cleaned up my Alcans a touch, swapped the hacked up yota spacers on my coil overs for proper Nisstec pieces, and gave everything a general once over. Now to get started on the install since all my pieces are finally here!

[zip ties]

Those tires look too big. Did you at least stick some boggers under that X?

[TerryD]

Those tires look too big. Did you at least stick some boggers under that X?

Hey Dave! That's the same size tire that some nut I know has on his 4x4 camp-a-gym-atorium of a van!

Boggers would be fun! I miss my Boggers....

[zip ties]

You you think I need bigger tires? I agree!

[TerryD]

I've said all along Rocks and 42s....

[TerryD]

Lift has begun!
Both Helwigs removed
Both shocks swapped
U-bolts off both sides
One Alcan in

Started around 5, worked about an hour and a half between pumping up neighborhood kids bike tires, a nice supper the wife fixed and packing everything back in the garage to close up for the night.

[zip ties]

Okay what are the details on this lift? Leafs in the rear? Any extra springs in the pack? What are you doing up front? Progressive?

[TerryD]

Rear is going from three leaf stock to a 7.5 leaf pack, +2.5" lift +500lb capacity. Shocks are Radflo and gong with Timbren active off-road bump stops which are more akin to helper springs. Also a u-bolt flip kit to get my nuts out of the dirt.

Front is IFS and very short travel so progressives aren't warranted. What I have are Bilstein 5100s converted to an adjustable coil-over with Fat Bob's Garage adjustable collars and currently fitted with Eibach 600lb/in coils. Since I'm going to have a plate bumper in a few months with a winch, I'm considering throwing on the 650lb/in coils I have for it instead of having to go back under it again in a few months.

[TerryD]

Rear lift is in. Just need to get new bolts for the bumps.

Hoping to at least get the front torn down tomorrow. Really need to be done by Saturday evening if at all possible!!
